Comparison of model pairs

Martin R. Smith martin.smith@durham.ac.uk

2026-03-06

library("neotrans")

hetModels <- c("hg_ki", "hg2_ki", "hg_b_ki", "hg_m_ki", "hg_bm_ki")
rmModels <- c("rm_by_n_ki", "rm_by_t_ki", "rm_by_nt_ki")
statModels <- c("by_ki", "by_n_ki", "by_nn_ki", "by_t_ki", "by_nt_ki")
nsModels <- c("ns_ki", "ns_n_ki", "ns_t_ki", "ns_nt_ki")
homModels <- c(statModels, nsModels)
kiModels <- c(statModels, rmModels, nsModels, hetModels)
nonRm <- setdiff(kiModels, rmModels)

marginals <- GetMarginals(KiProjects(), kiModels)
stdErr <- attr(marginals, "stdErr")
bestModel <- table(nonRm[apply(marginals[nonRm, ], 2, which.max)])

wd <- 6
mfr <- c(4, 2)
spaceForOma <- 1.02
OutputPlot("modelCmp", wd, wd * mfr[1] / mfr[2] * spaceForOma, function() {
  layout(rbind(c(1, 1, 2), c(3, 3, 4), c(5, 5, 6), c(7, 7, 8)), widths = c(1, 1, 2))
  par(oma = c(0, 0, 1, 0))
  ModelHeatmap(marginals[nonRm, ], stdErr[nonRm, ])
  Panel(1, 4, -1.6)
  counts <- bestModel[rev(nonRm)]
  barCol <- ModelCol(rev(nonRm))
  names(counts) <- ModelLabel(rev(nonRm))

  par(mar = c(4.71, 0.6, 0.3, 0.4), cex = 0.86)
  bp <- barplot(counts,
                horiz = TRUE,
                col = barCol,
                border = NA,
                las = 1,
                space = 0,
                axes = FALSE,
                yaxt = "n",
                xlab = "Number of times best ML",
                xlim = c(0, max(counts) * 1.1),
                ylim = c(0.5, length(counts) - 0.5))

  text(x = counts - 0.4, y = seq_along(counts) - 0.5, labels = counts,
       col = "white", font = 2)
  abline(v = 0)
  Panel(2, 0, -1.6)

  par(mar = c(2, 4, 2, 0.4))
  SpindleCompare(
    modelA = c("by_n_ki", "by_nt_ki", "ns_n_ki", "ns_nt_ki"),
    modelB = c("by_ki", "by_t_ki", "ns_ki", "ns_t_ki"),
    marginals = marginals,
    stdErr = stdErr
  )
  Panel(3, 4)
  text(2.5, 70, "\U2191 g\U2013l asymmetry improves ML")
  text(2.5, -16.35, "\U2193 gain\U2013loss symmetry improves ML", xpd = NA)

  SpindleCompare("by_nn_ki", "by_n_ki", marginals, stdErr)
  Panel(4)

  SpindleCompare(
    modelA = c("by_t_ki", "by_nt_ki", "ns_t_ki", "ns_nt_ki"),
    modelB = c("by_ki", "by_n_ki", "ns_ki", "ns_n_ki"),
    marginals = marginals,
    stdErr = stdErr
  )
  Panel(5)
  text(2.5, 13, expression("\U2191 Unlinking" ~ italic("t") ~ "improves ML"))
  text(2.5, -9.6, expression("\U2193 Linking" ~ italic("t") ~ "improves ML"))

  SpindleCompare(
    modelA = c("ns_ki", "ns_t_ki", "ns_n_ki", "ns_nt_ki"),
    modelB = c("by_ki", "by_t_ki", "by_n_ki", "by_nt_ki"),
    marginals = marginals,
    stdErr = stdErr
  )
  Panel(6)
  text(2.5, 48, expression("\U2191 Non-stnry model improves ML"))
  text(2.5, -20, expression("\U2193 Stationary model improves ML"), xpd = NA)



  hetMar <- marginals[hetModels, ]
  homMar <- marginals[homModels, ]
  bestHet <- apply(hetMar, 2, which.max)
  bestHom <- apply(homMar, 2, which.max)

  hhm <- rbind(
    marginals[hetModels, ],
    bestHet = hetMar[cbind(bestHet, seq_len(ncol(hetMar)))],
    bestHom = homMar[cbind(bestHom, seq_len(ncol(homMar)))]
    )

  hhSE <- rbind(
    stdErr[hetModels, ],
    bestHet = stdErr[hetModels, ][cbind(bestHet, seq_len(ncol(hetMar)))],
    bestHom = stdErr[homModels, ][cbind(bestHom, seq_len(ncol(homMar)))]
    )

  SpindleCompare("bestHet", "bestHom", hhm, hhSE)
  text(1, 62, expression("\U2191 Heterog. model improves ML"))
  Panel(7)

  SpindleCompare(
    modelA = c("hg2_ki", "hg_b_ki", "hg_m_ki", "hg_bm_ki"),
    modelB = c("hg_ki", "hg2_ki", "hg2_ki", "hg2_ki"),
    marginals = hhm,
    stdErr = hhSE,
    width = 0.91
  )
  Panel(8)
  text(2.5, 27.1, expression("\U2191 Complex model improves ML"))
  text(2.5, -15.2, expression("\U2193 Simple model improves ML"), xpd = NA)
})
